Can choose manual knife adjustment, pneumatic knife touch screen pneumatic knife clamping style.
Applicable products: solid wood panels, fibreboard, particleboard, MDF and other panels and other panel furniture Edge. Edge of the main PVC, polyester, melamine and wood, and so on.
Achieve results: a high degree of automation, high efficiency, high precision and high aesthetics.
Structural advantages: laser cutting steel plate base, a welded body made of solid deformation does not increase the stability of the machine to ensure that each processing department can work fine. Processing components imported motor and high- quality electrical components.
Technical Parameters
| Working thickness | 10-60mm |
| Min. working width | ≥60mm |
| Min. panel length | ≥160mm |
| Feeding speed | 18-24m/min |
| Tape thickness | 0.4-3mm |
| Air pressure | 0.6Mpa |
| Total power | 16.8KW |
| Voltage | 380v,50hz, 3phase |
| Power of main drive motor | 3.7KW |
| Weight | 3000kg |
| Overall size | 6800*1100*1600mm |
